Selected Products For Your Success
Schaublin
SWISS Quality
As a traditional Swiss company with more than 100 years of experience in the field of clamping technology, Schaublin offers a comprehensive program for tool and workpiece clamping.
In the machining center sector, current needs increasingly point to high-speed machining and continuously require higher levels of accuracy. At SCHAUBLIN, products have long been developed and manufactured for our customers’ machining centers. The products are continuously improved through tests and examinations.
Info SCHAUBLIN
Rue de la Blancherie 9
CH-2800 Delémont
Tel. +41 324 211 300
Fax +41 324 211 301
Product Overview
General Catalog
Pull-type collets, external or internal thread
Dead lenght collets & feedfingers
Tool collets & clamping nuts
Collet holder DIN 2080 + various
Collet and tool holder DIN 69871
Collet and tool holder ISO-DIN- BT for high-speed machining "HSC"
Collet and cutter holder - HSK holders for high-speed machining "HSC"
Collet and tool holder with quick change system
SRS Clamping System
With this clamping system the concentricity of the collet can be adjusted in such a manner that a runout of less than 0.002 mm can be achieved at any position of the workpiece.
Very precise and easily adjustable
Easy maintenance
Protected from dirt and shavings
Applicable with most collets and a large variety of machines
SPR25 Quick-Change System
The SPR25 quick-change system from Schaublin is ideal for resharpening work when grinding tools, as several collet changes have to be carried out throughout the day.
Manual or automatic change of the collet
75% reduction of set up time (Click-System)
High runout repeatability
Clamping range Ø3mm to Ø21mm
Hydronut – High Performance Cooling
The newest solution by Schaublin to efficiently bring fluid to the cutting edge. The nut is equipped with nozzle, which accelerates and directs the coolant, creating a concentric and stable flow
